Technical Specifications
Engineering data to help buyers prepare model, suffix, clearance, cage, bore, dimension, and document details before RFQ review.
Technical Routes for RFQ Preparation
Use this hub to prepare details before asking TFL Bearing to review availability, production, replacement, or document options. Dedicated technical pages should focus on practical RFQ tables as they are produced.
Clearance
C2, CN, C3, C4, C5, and application-specific clearance review
Suffixes
Cage, lubrication, bore, clearance, and design suffix preparation
Cage Types
CA, CC, MB, MA, and brass cage review for RFQ preparation
Tapered Bore
K, K30, shaft, and sleeve requirement preparation
Adapter & Withdrawal Sleeves
Sleeve and accessory details for tapered bore RFQs
HS Code
Export classification and customs document preparation can be reviewed with RFQ details
Dimensional Range
| Parameter | Range |
|---|---|
| Bore Diameter | 20mm – 500mm+ |
| Outer Diameter | 50mm – 620mm |
| Width | 12mm – 250mm |
| Bore Type | Cylindrical or Tapered (1:12, 1:30) |
Product Series
| Series | Load Characteristics | Typical Applications |
|---|---|---|
| 22200 | Medium-wide, moderate load | Fans, pumps, conveyors |
| 22300 | Wide, high load capacity | Steel mills, mining, heavy machinery |
| 23000 | Medium-wide, low cross-section | Limited radial space applications |
| 23100 | Wide, very high load capacity | Paper machines, marine, wind turbines |
| 23200 | Extra wide, maximum load | Extreme heavy-duty, continuous casting |
| 24000 | Wide, low cross-section | Limited space, moderate load |
| 24100 | Extra wide, low cross-section | Space-constrained heavy-duty |
Quality & Tolerance Standards
Tolerance Classes
- • Normal (P0) — standard industrial
- • P6 — improved precision
- • P5 — high precision
- • ABEC-1 through ABEC-5 equivalent
Internal Clearance
- • C2 — less than normal
- • CN — normal (standard)
- • C3 — greater than normal
- • C4, C5 — for high temperature / interference fits
Cage Types
- • CA — machined brass, prong-type
- • MB — machined brass, window-type
- • CC — stamped steel
- • MA — machined brass, outer ring centered
Material & Heat Treatment
- • GCr15 / 100Cr6 bearing steel
- • Through-hardened or case-hardened
- • Salt bath quenching process
- • 58–64 HRC raceway hardness
Need Detailed Engineering Data?
Contact our team with your specific requirements for detailed dimensional drawings, load calculations, and application-specific recommendations.
